Greene Fire’s Aluflam AF70 Fire Rated Awning Window combines fire protection, natural ventilation and contemporary architectural design in one innovative glazing system. Featuring thermally broken aluminium framing and specialised fire-resistant glass, the AF70 provides Fire Resistance Levels (FRLs) of up to –/60/60, making it a practical solution for external applications where fire protection and ventilation are required.

Designed with safety and functionality in mind, the AF70 is a self-closing, self-latching awning window that automatically closes upon fire detection through a fusible link mechanism. The system incorporates a patented fire-retardant insulating core and high-temperature gaskets, providing protection against fire, smoke and weather exposure.

With maximum dimensions of 1200 mm wide by 1500 mm high and an opening gap of up to 125 mm, the AF70 offers flexibility for architectural applications. Available with powder-coated or anodised aluminium finishes and compatible fire-rated glazing options, the system integrates seamlessly into modern building designs.

Tested in accordance with AS 1530.4 for fire resistance and AS 2047 for weather performance, Greene Fire’s fire-rated awning windows offer a specialised glazing solution for projects across Sydney, Melbourne and Australia. Final specifications and installation requirements are subject to the relevant system test and assessment documentation.

Window Types Available

Greene Fire offers the Aluflam AF70 Fire Rated Awning Window, a self-closing, self-latching glazed window system designed for applications requiring fire protection and ventilation.

The system features a thermally broken aluminium frame with a patented fire-retardant insulating core. It is designed to close automatically upon fire detection via a fusible link.

Available configuration:

Fire-rated awning window with FRL up to –/60/60, subject to the specified glazing and installation requirements.
Maximum overall size of 1200 mm wide × 1500 mm high.
Maximum openable gap of 125 mm.
External installation options, subject to the applicable fire assessment.

Framing

The Aluflam AF70 Fire Rated Awning Window incorporates non-corrosive, thermally broken aluminium framing with a patented insulating core.

The frame uses high-temperature gaskets to help provide fire, smoke and weather protection.

Framing features include:

61 × 70 mm aluminium framing profile.
Powder-coated (PPC) or anodised finishes.
Single- and double-glazing options, subject to system requirements.
Thermally broken construction for improved energy performance.
Fire-resistant and weather-tested construction.

Fire Rating

The Aluflam AF70 Fire Rated Awning Window is designed to provide fire integrity and insulation performance for external applications, with Fire Resistance Levels up to –/60/60, depending on the glazing configuration.

The product documentation references testing to AS 1530.4 and weather testing to AS 2047.

Available glazing configurations include systems offering up to 60 minutes of fire integrity and insulation performance.

The final FRL, glazing selection, dimensions and installation details must be confirmed against the relevant test and assessment documentation.

Specification	AF70 Awning Window
Product	Product
Frame	Frame
Maximum FRL	Maximum FRL
Maximum overall dimensions	Maximum overall dimensions
Maximum openable gap	Maximum openable gap
Operation	Self-closing, self-latching
Fire activation	Fusible link
Finish options	PPC or anodised
Fire testing	AS 1530.4
Weather testing	AS 2047
Installation	Masonry or lightweight stud wall, subject to assessment

How Does The Glass Work?

The AF70 Fire Rated Awning Window uses specialised fire-resistant glazing within an insulated aluminium frame.

Depending on the required fire rating and application, compatible glazing options include Pyrobel and Contraflam products.

These glazing systems are designed to resist fire exposure, with selected configurations also providing insulation performance to reduce heat transfer.

The final glass specification must be selected in accordance with the relevant tested or assessed system configuration.

Benefits

Fire-rated ventilation option where boundary protection is required.
Automatic self-closing operation via fusible link upon fire detection.
Fire Resistance Level up to –/60/60.
Slim, thermally broken aluminium framing.
Single- and double-glazing options.
Powder-coated or anodised finishes.
Maximum window size of 1200 × 1500 mm.
Maximum openable gap of 125 mm.
Fire and weather performance testing to relevant Australian Standards.

Learn More

For further technical information about the Aluflam AF70 Fire Rated Awning Window, please refer to the product brochure and technical documentation provided below.

Our team can assist architects, builders and fire safety professionals with glazing selection, fire resistance requirements, installation considerations and project-specific specifications.

To discuss your project requirements or request further information, contact Greene Fire on (02) 9526 3100 or email sales@greenefire.com.au.
