Greene Fire’s Aluflam BAL-FZ Fire Rated Window provides a specialised glazing solution for buildings located in designated bushfire-prone areas. Designed for applications requiring Bushfire Attack Level – Flame Zone (BAL-FZ) protection, the system combines fire-resistant glazing with thermally broken aluminium framing to deliver fire protection without compromising architectural design.

The BAL-FZ window system is designed to achieve a Fire Resistance Level (FRL) of –/30/–, subject to the applicable tested system and installation requirements. It incorporates Aluflam’s fire-resistant aluminium framing, specialised glazing and protective seals to support compliance with Australian bushfire construction requirements.

Under AS 3959, buildings located in BAL-FZ areas are subject to stringent construction requirements due to their potential exposure to direct flame contact and intense radiant heat. Depending on the applicable compliance pathway, window systems may require testing to AS 1530.8.2 or an appropriate fire resistance rating supported by AS 1530.4 testing.

Available with powder-coated or anodised aluminium finishes, Greene Fire’s BAL-FZ Fire Rated Windows provide an architectural glazing solution for residential and commercial developments in bushfire-prone areas across Australia. Final system selection, glazing specifications and installation details must be confirmed against the relevant test documentation and project requirements.

Window Types Available

Greene Fire offers the Aluflam BAL-FZ Fire Rated Window, a fixed glazing system designed for buildings located in designated bushfire-prone areas requiring Flame Zone protection.

The system incorporates fire-resistant glazing and thermally broken aluminium framing, providing an architectural window solution for applications subject to stringent bushfire construction requirements.

Available system:

BAL-FZ Fire Rated Fixed Window: Designed for BAL-FZ applications, with an FRL of –/30/– subject to the relevant tested configuration and compliance requirements.

The complete window assembly, including framing, glazing, seals and hardware, must meet the applicable requirements of AS 3959.

The appropriate glazing configuration and installation method must be confirmed against the relevant fire test reports and project-specific bushfire requirements.

Fire Rating

The Aluflam BAL-FZ Fire Rated Window is designed for applications requiring bushfire protection under AS 3959.

The product documentation identifies a Fire Resistance Level (FRL) of –/30/–, providing 30 minutes of fire integrity for the specified system configuration.

Under AS 3959, BAL-FZ represents the highest Bushfire Attack Level classification, applicable to buildings potentially exposed to direct flame contact.

Depending on the project requirements, compliance may be demonstrated through an appropriate fire-rated window assembly or testing in accordance with AS 1530.8.2.

Specification	AF70 Awning Window
Product	Aluflam BAL-FZ Fire Rated Window
Frame	Fixed glazing
Window Type	Thermally broken aluminium
Bushfire Classification	BAL-FZ
Fire Resistance Level	-/30/-
Fire integrity	30 minutes
Structural adequacy	Not required for stated FRL
Fire insulation	Not required for stated FRL
Relevant standards	AS 3959, AS 1530.4 and AS 1530.8.2, as applicable
Frame finishes	Powder-coated or anodised

How Does The Glass Work?

The Aluflam BAL-FZ Fire Rated Window incorporates specialised fire-resistant glazing designed to provide protection against fire exposure in bushfire-prone environments.

Unlike conventional window glazing, fire-resistant glass is designed to maintain its required performance under specified fire test conditions. When combined with the appropriate aluminium framing, seals and installation system, it forms part of a complete fire-resistant window assembly.

Bushfire protection requirements

Buildings classified as BAL-FZ may be exposed to direct flame contact, intense radiant heat and burning embers. As a result, window systems must satisfy the applicable requirements of AS 3959.

Depending on the approved compliance pathway, this may involve:

A window system tested in accordance with AS 1530.8.2.
An appropriately fire-rated window system supported by AS 1530.4 testing.

The Aluflam BAL-FZ window documentation identifies an FRL of –/30/–, representing 30 minutes of fire integrity without a specified insulation rating.

The performance of the complete window depends on the approved glazing, framing, seals, fixing details and installation method. All components must be selected in accordance with the relevant test documentation.

Learn More

For further technical information about the Aluflam BAL-FZ Fire Rated Window, please refer to the product brochure and relevant fire testing documentation provided below.

Our team can assist architects, builders, designers and fire safety professionals with bushfire glazing requirements, product selection, framing specifications and project-specific compliance considerations.

To discuss your project requirements or request further information, contact Greene Fire on (02) 9526 3100 or email sales@greenefire.com.au.
